APT horn flares are available separately for use with any driver with 1 3/8” ext. thread.
| SPECIFICATION | |
| Type | Radial |
| Throat Size | 1.0”, 25.4 mm |
| Attachment Method | Screw-on or Bolt-on (H290B) |
| Dispersion | 90 x 40 |
| RecommendedCrossover | 1.0 kHz) |
| Width/Height/Depth | 11.7” x 6.6” x 6.6”,297.2 x 167.6 x 167.6 mm |
| Cut-out | 9.7 x 4.9”,246 x 124 mm |
| Weight | 1.10 lb., 0.50 kg |
| Material | ABS |
| SPECIFICATION | |
| Type | Exponential |
| Throat Size | 1.4”, 35.6 mm |
| Attachment Method | Bolt-on |
| Dispersion | 60 X 40 |
| RecommendedCrossover | 600 Hz |
| Width/Height/Depth | 12.60” x 7.50” x 7.90”,320 x 190.5 x 200.7 mm |
| Cut-out | 11.3 x 6.1”,287 x 155 mm |
| Weight | 4.80 lb., 2.18 kg |
| Material | Aluminum |
| SPECIFICATION | |
| Type | Exponential |
| Throat Size | 2.0”, 50.8 mm |
| Attachment Method | Bolt-on |
| Dispersion | 60 x 40 |
| RecommendedCrossover | 700 Hz |
| Width/Height/Depth | 12.4” x 7.3” x 6.1”,315 x 185.4 x 154.9 mm |
| Cut-out | 11.3 x 6.3”,287 x 160 mm |
| Weight | 4.90 lb., 2.22 kg |
| Material | Aluminum |
| SPECIFICATION | |
| Type | Exponential |
| Throat Size | 1.0”, 25.4 mm |
| Attachment Method | Screw-on |
| Dispersion | 60 x 60 |
| RecommendedCrossover | 1.2 kHz |
| Width/Height/Depth | 5.59” x 5.59” x 4.38”,142 x 142 x 111.3 mm |
| Cut-out | 3.56 x 3.56”,90.4 x 90.4 mm |
| Weight | 0.35 lb., 0.16 kg |
| Material | ABS |
| SPECIFICATION | |
| Type | Constant Directivity |
| Throat Size | 1.0”, 25.4 mm |
| Attachment Method | Bolt-on |
| Dispersion | 90 x 40 |
| RecommendedCrossover | 1.0 kHz |
| Width/Height/Depth | 9.8” x 7.7” x 5.2”,249 x 196 x 132 mm |
| Cut-out | 8.5” x 6.4”,216 x 163 mm |
| Weight | 1.80 lb., 0.82 kg |
| Material | ABS |
High power subwoofer recommended for vented and horn loaded enclosures. Truncated chassis allows for close placement in tight fitting applications.
» Read More
Recommended as a woofer, midbass or midrange in sealed and vented enclosures. A popular choice for 12” line arrays and bass guitar applications.
» Read More
Lightweight high power midbass driver. When used as a true midrange, a small sealed box will work. When used as a midbass, use a vented box.
» Read More
High power subwoofer recommended for vented and horn loaded enclosures. Truncated chassis allows for close placement in tight fitting applications.
» Read More
Throat Size: 1.0", 25.4 mm
Nominal Impedance*: 8 or 16 Ω
Minimum Impedance: 9.0 ohm @ 5.9 kHz
» Read More
Throat Size: 1.0", 25.4 mm
Nominal Impedance*: 8 or 16 Ω
Minimum Impedance: 8.7 ohm @ 5.3 kHz
» Read More
Recommended for professional audio and bass as a high power, low distortion subwoofer in single or multi-driver designs.
» Read More
High power driver recommended for pro audio in vented enclosures. Suited for full-range three-way boxes, bass guitar boxes, and small subwoofers.
» Read More
The Kappa Pro 18LF provides tons of low frequency output in a lightweight, durable cast aluminum chassis.
» Read More
Recommended for professional audio subwoofer and woofer applications in sealed and vented enclosures.
» Read More
The PA40BAT Battery Powered 40-Watt P.A. System is a portable all-in-one package that combines quality performance and convenient features.
» Read More
The Kustom KPX112PM powered monitor cabinet packs a lot of value into an affordable package. This full-range cab offers fantastic audio quality.
» Read More
Kustom KXB Series amplifiers are for those who want to produce great tone, rugged reliability and intuitive tone-shaping.
» Read More
High power subwoofer recommended for vented and horn loaded enclosures. Truncated chassis allows for close placement in tight fitting applications.
» Read More
Recommended as a woofer, midbass or midrange in sealed and vented enclosures. A popular choice for 12” line arrays and bass guitar applications.
» Read More
65-watt combo amplifier with a 12-inch speaker that is specifically designed to reproduce and enhance the natural sound.
