| SPECIFICATION | |
| Throat Size | 1.4", 35.6 mm |
| Nominal Impedance* | 8 Ω |
| Minimum Impedance | 6.7 ohm @ 3.7 kHz |
| Power Rating* | 100 W (AES) |
| Resonance | 550 Hz |
| DC Resistance (Re) | 4.80 Ω |
| Usable Frequency Range | 800 Hz - 20 kHz |
| Recommended Crossover | 800 Hz / 12 dB |
| Sensitivity* | 110.9 dB |
| Magnet Material | Neodymium |
| Magnet Weight | 11 oz, 0.31 kg |
| Voice Coil Diameter | 3.0", 76 mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | Titanium |
| MOUNTING INFORMATION | |
| Overall Diameter | 5.72", 145.3 mm |
| Driver Volume Displaced | 0.023 cu.ft., 0.66 liters |
| Depth | 2.53”, 64.3 mm |
| Net Weight | 5.1 lb, 2.3 kg |
| Shipping Weight | 5.4 lb, 2.4 kg |
| Mounting Thread | N/A |
| Mounting Holes Diameter | 4X 1/4-20 |
| Mounting Holes B.C.D. | 4.00”, 101.6 mm |
| SPECIFICATION | |
| Throat Size | 2.0", 50.8 mm |
| Nominal Impedance* | 8 Ω |
| Minimum Impedance | 6.7 ohm @ 3.6 kHz |
| Power Rating* | 100 W (AES) |
| Resonance | 520 Hz |
| DC Resistance (Re) | 4.80 Ω |
| Usable Frequency Range | 800 Hz - 20 kHz |
| Recommended Crossover | 800 Hz / 12 dB |
| Sensitivity* | 110.4 dB |
| Magnet Material | Neodymium |
| Magnet Weight | 11 oz, 0.31 kg |
| Voice Coil Diameter | 3.0", 76 mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | Titanium |
| MOUNTING INFORMATION | |
| Overall Diameter | 5.72", 145.3 mm |
| Driver Volume Displaced | 0.023 cu.ft., 0.66 liters |
| Depth | 2.53”, 64.3 mm |
| Net Weight | 5.1 lb, 2.3 kg |
| Shipping Weight | 5.4 lb, 2.4 kg |
| Mounting Thread | N/A |
| Mounting Holes Diameter | 4X 1/4-20 |
| Mounting Holes B.C.D. | 4.00”, 101.6 mm |
| SPECIFICATION | |
| Throat Size | 1.0", 25.4 mm |
| Nominal Impedance* | 8 Ω |
| Minimum Impedance | 7.4 ohm @ 6.1 kHz |
| Power Rating* | 35 W (AES) |
| Resonance | 2.1 kHz |
| DC Resistance (Re) | 6.30 Ω |
| Usable Frequency Range | 3.5 kHz - 20 kHz |
| Recommended Crossover | 3.5 kHz / 12 dB |
| Sensitivity* | 104.7 dB |
| Magnet Material | Ferrite |
| Magnet Weight | 8 oz, 0.23 kg |
| Voice Coil Diameter | 1.0", 25 mm |
| Voice Coil Former | Kapton |
| Diaphragm Material | Phenolic |
| MOUNTING INFORMATION | |
| Overall Diameter | 2.75", 69.9 mm |
| Driver Volume Displaced | 0.004 cu.ft., 0.12 liters |
| Depth | 2.53”, 64.3 mm |
| Net Weight | 1.70 lb, 0.8 kg |
| Shipping Weight | 2.00 lb, 0.9 kg |
| Mounting Thread | Use Apt Horn or Adapter |
| Mounting Holes Diameter | N/A |
| Mounting Holes B.C.D. | N/A |
| SPECIFICATION | |
| Throat Size | 1.0", 25.4 mm |
| Nominal Impedance* | 8 Ω |
| Minimum Impedance | 7.7 ohm @ 3.0 kHz |
| Power Rating* | 50 W (EIA-426A) |
| Resonance | 592 Hz |
| DC Resistance (Re) | 6.70 Ω |
| Usable Frequency Range | 2.5 kHz - 20 kHz |
| Recommended Crossover | 2.5 kHz / 18 dB |
| Sensitivity* | 104.4 dB |
| Magnet Material | Ferrite |
| Magnet Weight | 12 oz, 0.34 kg |
| Voice Coil Diameter | 1.3", 33 mm |
| Voice Coil Former | Aluminum |
| Diaphragm Material | Titanium |
| MOUNTING INFORMATION | |
| Overall Diameter | 3.50", 88.9 mm |
| Driver Volume Displaced | 0.009 cu.ft., 0.26 liters |
| Depth | 2.45”, 62.2 mm |
| Net Weight | 1.70 lb, 0.8 kg |
| Shipping Weight | 2.00 lb, 0.9 kg |
| Mounting Thread | 1 3/8 in. 18 ext. |
| Mounting Holes Diameter | 2X M6 |
| Mounting Holes B.C.D. | 3.0”, 76.2 mm |
| SPECIFICATION | |
| Throat Size | 1.0", 25.4 mm |
| Nominal Impedance* | 8 or 16 Ω |
| Minimum Impedance | 7.6 ohm @ 3.7 kHz |
| Power Rating* | 80 W (AES) |
| Resonance | 540 Hz |
| DC Resistance (Re) | 6.10 Ω |
| Usable Frequency Range | 1.2 kHz - 20 kHz |
| Recommended Crossover | 1.2 kHz / 12 dB |
| Sensitivity* | 106.1 dB |
| Magnet Material | Ferrite |
| Magnet Weight | 34 oz, 0.96 kg |
| Voice Coil Diameter | 2.0", 51 mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | Titanium |
| MOUNTING INFORMATION | |
| Overall Diameter | 5.25", 133.4 mm |
| Driver Volume Displaced | 0.018 cu.ft., 0.50 liters |
| Depth | 2.20”, 55.9 mm |
| Net Weight | 4.70 lb, 2.1 kg |
| Shipping Weight | 5.00 lb, 2.3 kg |
| Mounting Thread | 1 3/8 in. 18 ext. |
| Mounting Holes Diameter | 2X 1/4-20 or 3x M6 |
| Mounting Holes B.C.D. | 3.0”, 76.2 mm |
| SPECIFICATION | |
| Throat Size | 1.0", 25.4 mm |
| Nominal Impedance* | 8 or 16 Ω |
| Minimum Impedance | 8.7 ohm @ 5.3 kHz |
| Power Rating* | 85 W (AES) |
| Resonance | 438 Hz |
| DC Resistance (Re) | 6.80 Ω |
| Usable Frequency Range | 1.5 kHz - 20 kHz |
| Recommended Crossover | 1.5 kHz / 12 dB |
| Sensitivity* | 108.3 dB |
| Magnet Material | Ferrite |
| Magnet Weight | 34 oz, 0.96 kg |
| Voice Coil Diameter | 2.0", 51 mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | Titanium |
| MOUNTING INFORMATION | |
| Overall Diameter | 5.25", 133.4 mm |
| Driver Volume Displaced | 0.018 cu.ft., 0.51 liters |
| Depth | 2.30”, 58.4 mm |
| Net Weight | 5.60 lb, 2.5 kg |
| Shipping Weight | 5.90 lb, 2.7 kg |
| Mounting Thread | 1 3/8 in. 18 ext. |
| Mounting Holes Diameter | 2X 1/4-20 |
| Mounting Holes B.C.D. | 3.00”, 76.2 mm |
| SPECIFICATION | |
| Throat Size | 1.4", 35.6 mm |
| Nominal Impedance* | 8 Ω |
| Minimum Impedance | 6.8 ohm @ 2.5 kHz |
| Power Rating* | 100 W (AES) |
| Resonance | 419 Hz |
| DC Resistance (Re) | 4.80 Ω |
| Usable Frequency Range | 800 Hz - 20 kHz |
| Recommended Crossover | 800 Hz / 12 dB |
| Sensitivity* | 108.4 dB |
| Magnet Material | Ferrite |
| Magnet Weight | 80 oz, 2.27 kg |
| Voice Coil Diameter | 3.0", 76 mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | Titanium w/ geodesic ribs for increased stiffness and break-up control. |
| MOUNTING INFORMATION | |
| Overall Diameter | 7.90", 200.7 mm |
| Driver Volume Displaced | 0.048 cu.ft., 1.36 liters |
| Depth | 3.10”, 78.7 mm |
| Net Weight | 13.40 lb, 6.1 kg |
| Shipping Weight | 13.70 lb, 6.2 kg |
| Mounting Thread | |
| Mounting Holes Diameter | 4X 1/4-20 |
| Mounting Holes B.C.D. | 4.00”, 101.6 mm |
| SPECIFICATION | |
| Throat Size | 2.0", 50.8 mm |
| Nominal Impedance* | 8 Ω |
| Minimum Impedance | 7.1 ohm @ 3.4 kHz |
| Power Rating* | 100 W (AES) |
| Resonance | 470 Hz |
| DC Resistance (Re) | 4.80 Ω |
| Usable Frequency Range | 800 Hz - 20 kHz |
| Recommended Crossover | 800 Hz / 12 dB |
| Sensitivity* | 108.8 dB |
| Magnet Material | Ferrite |
| Magnet Weight | 80 oz, 2.27 kg |
| Voice Coil Diameter | 3.0", 76 mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | Titanium w/ geodesic ribs for increased stiffness and break-up control. |
| MOUNTING INFORMATION | |
| Overall Diameter | 7.90", 200.7 mm |
| Driver Volume Displaced | 0.048 cu.ft., 1.36 liters |
| Depth | 3.10”, 78.7 mm |
| Net Weight | 13.20 lb, 6.0 kg |
| Shipping Weight | 13.50 lb, 6.1 kg |
| Mounting Thread | |
| Mounting Holes Diameter | 4X 1/4-20 |
| Mounting Holes B.C.D. | 4.0”, 101.6 mm |
| SPECIFICATION | |
| Throat Size | 1.0", 25.4 mm |
| Nominal Impedance* | 8 or 16 Ω |
| Minimum Impedance | 9.0 ohm @ 5.9 kHz |
| Power Rating* | 50 W (AES) |
| Resonance | 578 Hz |
| DC Resistance (Re) | 6.80 Ω |
| Usable Frequency Range | 1.5 kHz - 20 kHz |
| Recommended Crossover | 1.5 kHz / 12 dB |
| Sensitivity* | 109.0 dB |
| Magnet Material | Neodymium |
| Magnet Weight | 4 oz, 0.11 kg |
| Voice Coil Diameter | 2.0", 51 mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | Titanium |
| MOUNTING INFORMATION | |
| Overall Diameter | 3.87", 98.3 mm |
| Driver Volume Displaced | 0.008 cu.ft., 0.22 liters |
| Depth | 1.75”, 44.5 mm |
| Net Weight | 1.70 lb, 0.8 kg |
| Shipping Weight | 2.00 lb, 0.9 kg |
| Mounting Thread | 1 3/8 in. 18 ext. |
| Mounting Holes Diameter | 2X 1/4-20 |
| Mounting Holes B.C.D. | 3.0”, 76.2 mm |
